9CU ultra high output LED tape (10m)
ENTTEC designs and manufactures a complete range of high-quality LED strips to suit any desired mood or effect.
9CU tape comes in different colour temperatures so you can choose the white you require.
Features
Ultra high output
Thanks to the ultra high output configuration, the maximum at 3000K or 6000K is 1700 lumens per metre.
24V white range in 3000K, 4000K or 6000K
9CU is a 24V white LED tape. Choose from Warm White (3000K), Natural White (4000K), or White (6000K) colour temperatures.
Input current and wattage
Maximum input current rating is 0.85 A per metre which equals 4.25 A for a 5-metre length. 9CU consumes a maximum of 20.4W per metre, and the maximum continuous length is 6 metres.
Specifications
| DC Power | W/m | LED Quantity | Product Family | Product Code | Colour | #colspan# | Lm/m | Input Current 1M | Input Current 5M | IP | Reel Length | Strip Width | Cuttable | Maximum Continuous Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 24V | 20.4 | 120/m | 9CU | 9CU1 | White | 6000K | 1700 | 0.85A | 4.25A | 20 | 10m | 11mm | 50mm | 6m |
| #rowspan# | #rowspan# | #rowspan# | #rowspan# | 9CU2 | Natural White | 4000K | #rowspan# | #rowspan# | #rowspan# | #rowspan# | #rowspan# | #rowspan# | #rowspan# | #rowspan# |
| #rowspan# | #rowspan# | #rowspan# | #rowspan# | 9CU3 | Warm White | 3000K | #rowspan# | #rowspan# | #rowspan# | #rowspan# | #rowspan# | #rowspan# | #rowspan# | #rowspan# |
