METAL SMART PXL40 DOT

Flexible strings of ultra-bright, high-resolution 41.5mm RGB LED nodes with robust, aluminum cases for all-weather use

SKU: 73010-73011-73012-2

Overview
Features
Connectivity
Specifications
Resources

Individually addressable, LED pixel dot lights

ENTTEC’s SMART PXL40 LED pixel dots feature robust, weatherproof UV-resistant PVC cases. For projects requiring metal fixtures, we offer a 41.5mm version made from marine-grade aluminum, machined, and anodized at our Australian HQ. These versatile, easy-to-install RGB dots create striking lighting effects and can be customized for any project. Designed by professionals, they elevate any architectural, commercial, or entertainment space.

Constructed from premium durable materials in our Australian factory, SMART PXL dots offer outstanding protection against moisture (IP67), corrosion and impact (IK10), and come with a 3-year warranty. The perfect outdoor pixel light for all projects.

Because your projects are built to custom specifications, so are our metal SMART PXL40 dots. Select from different lens options and custom spacing from anywhere between 125mm and 1200mm between each dot.

Each direct-view SMART PXL node contains 6 premium RGB LED chips, giving an impressive lumen output. They look amazing from a distance and have been used to great effect around the world on everything from bridges to ferris wheels.

16-bit native for an ultra-smooth dimming curve and mixing detail that will truly wow your audience. Alternatively, run them in 8-bit mode with an ENTTEC control system to halve the required control channels.

We use custom made quality cable to combat voltage drop, ensuring you a richness and consistency of colour. With the best combination of customisation, you’ll be able to achieve long runs of up to 70 dots without power injection. Talk to our friendly sales team now to understand the full potential of your design!

The versatile nature of SMART PXL dot strings means they’re easy-to-install around tricky angles, corners or bends, making them ideal to show off or highlight architectural features. Talk with an ENTTEC expert and we can help you bring almost any design you can imagine to life.

Accessories

PXL-40 LED pixel dot accessories

At ENTTEC, we know that well-considered design is key to a successful installation. Our team have created a leading range of innovative accessories with premium cabling and connectors to support your project and make specifying and installing the SMART PXL series simple. For peace of mind, our 24V and 48V accessories also feature different pinouts to prevent damage being caused when using different voltages.

Specifications

led channels	RGB (Red/Green/Blue)
Colour resolution	16-bit (can also run in 8-bit mode)
Control protocol	ENTTEC SPXL-8 / SPXL-16
Data configuration	auto-addressing
LED lifetime	50,000 hrs (L70)
Body material	machined and anodised 6032 aluminium
Lens options	⌀41.5mm diffuse dome / clear flat / no lens
Lens material	optical grade polycarbonate
IK rating	IK10
IP rating	IP67
Vibration rating	3G
Operating temperature	-20°C to +50°C
Overall dimensions	77.2mm L x 57mm W x 14mm H (no lens) / 31.2mm H (dome lens) / 22.1mm H (flat lens)
Weight	1.00 kg (string of 20 dots)
Dot pitch/spacing	customisation options available: from 125mm to 2000mm
Installation	2 x ⌀4.3mm mounting holes for M4 screws
Cabling	includes premium Amphenol AT series connectors
Compliance	CE / WEEE / RoHS (EU), UKCA (UK)
Warranty	3-year return-to-base manufacturer warranty as standard. Talk to us to arrange longer periods

LEDs

LED source	6 x RGB SMD3535 – customisation options available
Input voltage	24V DC
Max lumens (lm)	no lens: 33 / flat lens: 29 / dome lens: 24
Efficacy (max lm/watt)	no lens: 22 / flat lens: 19.3 / dome lens: 16
Control channels	equivalent of 6 DMX channels of data per dot
Dots controllable per DMX universe	8-bit: 170 / 16-bit: 85
